Transparent Heating Film

Technical Parameter

◆ The visible transparency is up to 85%, higher than that of traditional glass.
◆ No harmful effects from glare. When attached to a screen, the transparent film heating element [maintains] a good image quality.
◆ Lightweight and ultra thin. Heats up quickly and evenly, can reach the temperature (50ºC) as set and with stand a temperature up to 120ºC.
◆ It can be self adhesive, is space-saving, and is easy and convenient to operate.
◆ Any dimension, specification or shape can be developed and customized as per the requirements of customers.
◆ Voltage can be set from 1.5V to 380V for design and production.

Iterative Method

The product is made of Protective Film (PE) + Blackened layer + Cu Layer + Substrate Layer (COP) + Protective Film (PET).

Application Areas

◆ Helmet for construction, motocycle, Outdoor CCTV, Camera for anti-fog；
◆ Outdoor LCD display, LED display,outdoor glass；
◆ Automobile glass, outdoor meter,portable computer, optical len,glasses, LCD panel,anti-fog window etc.

Product Advantages

◆ A heater that uses a film of laminated transparent conductive films such as ITO as a heating element.
Advantages: Transparent sheet material, no problem of wiring appearance.
Disadvantages: It takes a long time to heat up because of high resistance.
Although it can handle gently curved surfaces, cracks will occur in the transparent
conductive film when formed into a three-dimensional shape.

◆ A heater that uses a metal wire such as copper as a heating wire and patterns it on a film.
Advantages: The temperature rises relatively quickly due to low resistance.
Disadvantage: Generally, the heating wire heater has a thick wire, so the wiring can be seen.

◆ Transparent Heating Film developed by our company, which uses a unique patterning technology to form
a special heating wire pattern, has the following features:
Immediate heating + high transparency
Low resistance and invisible wiring, realizes a heater with rapid heating and high transparency.
Radio wave transparent
By controlling the shape of the wiring pattern, it is possible to secure not only visibility
but also radio wave transparency.
Three-dimensional shapes
Film can be formed into a three-dimensional shape without worrying about cracks.

Customization

After years of precipitation and accumulation, our company has a complete R&D and production system to provide customers with overall solutions, and provide personalized customized services according to design plans and requirements. We always adhere to customer-oriented, tailor-made for customers. best solution needed.

Excellent Physical Properties

High and low temperature test
The industry standard is: -30°C to +70°C, our Metal Mesh can reach -85°C to +85°C, and it can be used normally in extreme environments;
Environmental test: The test product functions normally at -80°C, 100°C (boiling water), and -235°C.

Cyclic bend test
Bending degree: from 0~90~180 degrees (cyclic bending), bending diameter: 4mm, 8mm;
After cycling 10k, 50k and 200k times, the resistance value of the display channel did not change.

Loop folding test
When the bending diameter is ≤4mm, and the bending angle is folded from 20 degrees to 180 degrees, the metal mesh can be used normally, and the folding touch can be realized.
